- Automatic draining system, stops bacteria proliferating
- Protection against no inlet water
- Less maintenance required when demineralised water is used
- Self-extinguishing plastic
- Built-in controller with simple, intuitive LED user interface
Ideal in the following applications
| Models | UHF | |
|---|---|---|
| MIST PRODUCTION | ||
| Production capacity | [Kg/h] | 1 |
| Maximum pressure | [mm H2O/bar] | 0,0023-23 |
| Pipe connection external diameter | [mm] | 50 |
| MIST DISTRIBUTION | ||
| Number of linear distributors that can be connected | [n] | 1 |
| Air capacity | [m3/h] | 11 |
| ELECTRICAL PROPERTIES | ||
| Power consumption | [kW] | 0.076 |
| Power supply | [Vac, Hz] | 230, 50 |
| Phases | [n] | 1 |
| Absorbed current | [A] | 0.5 |
| WATER PROPERTIES | ||
| Inlet water quality | Complies with microbiological standards for drinking water established by regulations in force where installed; completely or partially demineralised water is recommended to reduce routine maintenance | |
| Inlet water conductivity | μS*cm | 0...1250 |
| Inlet water hardness | °f | recommended 0...50 suitable up to 50 |
| Inlet water pressure | [MPa/bar] | 0...1/0...10 |
| Inlet water connection | JG8 | |
| Water drain external dimensions | [mm] | 16 |
| GENERAL CHARACTERISTICS | ||
| Dimensions | (WxHxD [mm]) | 85x173x126 |
| Weight | [kg] | 1.7 |
| IP protection | 30 | |
| CONTROL | ||
| Type of controller | built-in | |
| Command signal | 0-10 V o ON-OFF | |
